LTE Cat M Modem with GNSS USR-MB706
LTE Cat M serial modem USR-MB706

Function Block

Basic Funstion of LTE Cat M serial modem USR-MB706

Basic Funstion

USR-MB706 quickly delivers the bi-directional transparent transmission
of data at serial ports and networks.

Serial Cellular Modem Support Modbus RTU to TCP USR-MB706

Modbus RTU to TCP

Modbus RTU/Modbus TCP protocol conversion for
industrial SCADA systems and field devices.

Serial Cellular Modem/cellular modem/LTE cat M DTU USR-MB706

Supports GNSS and positioning information reporting

USR-MB706 supports multiple positioning modes, including GPS, beidou, glonass
and galileo, which can be configured by AT commands and output the positioning
format of international standards.

Serial Cellular Modem/cellular modem/LTE cat M DTU USR-MB706

Registration Package plus
Heartbeat Package

The registration packet is sent to the server to identify the device.
The heartbeat packet is used to judge the active state of the device when sent to the
server, and actively collect data when sent to the serial terminal.
The contents of registration package and heartbeat package, heartbeat interval can
be modified by AT command.

Serial Cellular Modem/cellular modem/LTE cat M DTU USR-MB706

Designed with Qualcomm MDM9205 communication module

Parameter Configuration of LTE Cat M serial modem USR-MB706

Parameter Configuration

Support the parameter configuration of serial,
network and SMT AT commands, and provide the configuration tool for the PC.

Serial Cellular Modem/cellular modem USR-MB706

Remote FOTA Upgrade

With the remote management platform,
it can realize the automatic firmware upgrade
Have a small upgrade package of differential algorithm,
and this can save upgrade traffic and time.

Serial Cellular Modem/cellular modem USR-MB706
Product Details of Serial Cellular Modem/cellular modem USR-MB706
Application of Serial Cellular Modem/cellular modem USR-MB706

Application Cases of Vehicle Monitoring

MB706 can upload the vehicle information to the cloud, the cloud monitoring
personnel can monitor the vehicle status in real time to achieve intelligent
process management.

Serial Cellular Modem/cellular modem USR-MB706

Meter reading

Smart meters are crucial components of the Smart Grid and enable two-way communication by interfacing remotely
with the utility and deliver meter readings automatically.
By gathering and forwarding data, smart meters allow consumers to make informed decisions to alter usage and
optimize electricity consumption. It also helps utilities to better monitor the electric system and demand response to
reduce peak loads, prevention of outages.Through the connection with MB706, all the serial data will be sent to
SCADA software via LTE CAT M1 and NB-IoT network.
