Model
|
U200S
|
U200L
|
U200C
|
|
Feature
|
5G + WiFi6
|
4G + WiFi6
|
WiFi6
|
|
CPU
|
Processor
|
IPQ5018,Dual-core ARM Cortex-A53@1GHz
|
|
Memory
|
RAM: 512M,DDR3
Flash: 128M
|
|
Cellular
|
Cellular module
|
Qualcomm Snapdragon X62/RM520NGLAA
|
EM05GFA
|
--
|
|
Frequency Bands
|
5G NR SA/NSA:n1/n2/n3/n5/n7/n8/n12/n13/n14/n18/ n20/n25/n26/n28/n29/n30/n38/n40/n41/n48/ n66/n70/n71/n75/n76/n77/n78/n79 LTE FDD:B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/ B17/B18/B19/B20/B25/B26/B28/B29/ B30/B32/B66/B71
LTE TDD: B34/B38/B39/B40/B41/B42/B43//B48
WCDMA:B1/B2/B4/B5/B8/B19
|
LTE FDD:B1/B2/B3/B4/B5/B7/B8/B12/B13 /B14/B18/B19/B20/B25/B26/B28/B66/B71 LTE TDD:B38/B39/B40/B41
WCDMA:B1/B2/B4/B5/B6/B8/B19
|
--
|
|
Rate
|
5G SA Sub-6: Max. 2.4 Gbps (DL)/Max. 900 Mbps (UL)
5G NSA Sub-6: Max. 3.4 Gbps (DL)/Max. 550 Mbps (UL)
LTE-FDD: Max. 1.6 Gbps (DL)/Max. 200 Mbps (UL)
HSPA+ : Max. 42Mbps (DL)/Max. 5.76Mbps (UL)
|
LTE-FDD: Max. 150Mbps (DL)/Max. 50 Mbps (UL)
WCDMA：Max. 42Mbps (DL)/Max. 5.76Mbps (UL)
|
--
|
|
Antennas
|
4* 5G internal antennas, 3DBI
|
2*4G internal antennas, 3DBI
|
--
|
|
MIMO
|
4*MIMO
|
2*MIMO
|
|
|
SIM slot
|
1*Nano SIM
|
1*Nano SIM
|
--
|
|
WiFi
|
Wi-Fi Chipsets
|
2.4G: IPQ5018
5GHz: Qualcomm QCN6102
|
|
Wi-Fi Standards
|
IEEE 802.11 a/b/g/n/ac/ax
|
|
Frequency Bands
|
2.4G: 2.412GHz - 2.484GHz
5.8G: 5.15GHz～5.85GHz
|
|
Rates
|
2.4G: 574 Mbps
5.8G: 2402 Mbps
|
|
End users
|
Up to 128
|
|
Antennas
|
2*internal antennas, 3DBI
|
|
Encryptions
|
WPA/WPA2, WPA3
|
|
Tx power
|
Up to 27dBm(Configurable according to different country)
|
|
Ethernet
|
WAN/LAN
|
1* Gigabit WAN/LAN(RJ45), auto MDI/MDIX
|
|
LAN
|
3* Gigabit LAN(RJ45), auto MDI/MDIX
|
|
Power supply
|
Standard Power
|
12V/2A
|
|
Consumption
|
Average: 600mA/12V
Max: 1100mA/12V
|
|
Connector
|
DC socket 5.5*2.1
|
|
Physical characteristics
|
Dimension
|
180*90.73*90.93
|
|
Housing
|
ABS Material
|
|
Installation
|
Desktop,
|
|
Operating Temperature
|
0℃~+55℃
|
|
Weight
|
493.1g
|
493.1g
|
493.1g
|
|
Humidity
|
1%-95% (No-condensing)
|
|
Other interface
|
Reset button
|
Press and hold for 5-15s to reset to factory settings
|
|
Indicators
|
Power, WiFi, 4G, 5G
|
|
Software
|
WiFi mode
|
AP/router/repeater
|
|
WAN connectivity
|
DHCP/PPPoE/Static IP
|
|
MAC Clone
|
√
|
|
Cellular relevence
|
APN settings, PDP(IPv4/IPv4v6),SIM authentication settings, PIN settings, network detection, AT command
|
|
WiFi relevence
|
AP isolation, SSID hiding, 802.11r, signal level selection
|
|
LAN interface
|
DHCP server
|
|
Black/white list
|
√
|
|
IP blinding
|
√
|
|
Firmware upgrade
|
WebUI upgrade, online upgrade
|
|
Backup/restore
|
Backup current settings and restore the backup settings (Export/Import Configuration)
|
|
Time setting
|
Manual/auto
|
