Ethernet to RS485 Converter is an industrial serial server equipment with high-specification electrical protection, ISO9001 international quality certification, protocol stack technology, no downtime, no crash, no data loss, 2-year warranty for the whole machine, lifelong technical support service, and can operate in the environment of -40 ℃ -85 ℃. Imported chip, independent CPU.RS485 serial port to Ethernet, 5-36V wide voltage power supply, software + hardware + CPU three-level watchdog stability without downtime.
The RS485/RS232 serial port is linked to the Ethernet for transparent data transmission, supports TCP, UDP, DNS, DHCP, PPPoE, Modbus RTU/TCP and other network protocols, and supports multiple host computer modes and configuration software.
With 10 years of experience in protocol stack optimization, the private protocol has been optimized repeatedly for 10 years. When the user chooses the private protocol TCP-ZSD and UDP-ZSD, the host computer is linked to run more stably.
Support multiple working modes of TCP Server, TCP Client, UDP Server, TCP-ZSD, UDP Client and UDP-ZSD.
Support DNS dynamic domain name resolution, connect to the server without fixed IP, support baud rate setting, select 300bps-115200 bps, start bit/stop bit/parity optional.
Rapid acquisition of RS485/RS232 serial devices provides acquisition instruction set and manual technical support. Modbus polling supports master-slave station mechanism, which can acquire multiple RS485 serial devices. Modbus polling master-slave station mechanism supports about 20 devices at most. RS485 device polling can configure multiple acquisition instructions through configuration software. Actively and periodically collect and distribute data.
Support local configuration and network remote configuration parameters to match the front-end equipment, and quickly view the current parameters of the equipment.Quickly configure the network communication protocol, data center address, local logic, polling parameters and other operating parameters, quickly diagnose the operating status of the equipment, test the data acquisition function, provide control mode command documents, and support users to develop software to control equipment parameters.
Support direct configuration of parameters under WEB webpage and chrome browser.
PUSR CLoud transparent transmission end platform server is used. Cloud transparent transmission end software provides SDK and supports secondary development. 485 serial server equipment can be tested quickly through virtual serial port technology. A complete set of test software and video tutorials are provided.
Provide data center OCX control, provide self-built center SDK Demo routine source code, support VB, VC, DELPHI, C # and other development languages, users can quickly establish the host computer center.
Ethernet to RS485 Converter supports sending data in LAN UDP broadcast mode. Multiple computers in the LAN create UDP virtual serial ports through the VCOMM virtual serial port tool, and the virtual serial ports can receive the message content in real time.
Using PUSR CLoud transparent transmission end platform, based on virtual serial port mode, it can seamlessly connect Kingview/Force Control/Zijinqiao and other mainstream configuration software testing, and also support self-built server test configuration software, and support Modbus RTU to Modbus TCP.
Built-in cache area, built-in bidirectional data cache area, automatic data cache, first-in first-out, after the wireless network is temporarily interrupted and recovered, the data in the cache area is automatically retransmitted, the data is not lost, the network response mechanism is supported, and the network fluctuation disconnection is automatically reconnected.
The heartbeat package ensures that the communication with the base station is not offline. The Ethernet to RS485 Converter can automatically maintain reliable communication with the data center for a long time, support the definition of automatic registration package, and automatically send the registration message content after the equipment is online. Support custom packet prefix, the monitoring center is easier to distinguish the data of each device, can set the MAC address.
It supports users to write scripts freely, control each channel and control function of serial server, and can realize active acquisition of up to 30 devices. Serial server can also directly realize relay control without complex C language programming.
Support quick view of current parameters of the device. Quickly configure the network communication protocol, data center address, local logic, polling parameters, and working parameters. Quickly diagnose the operation status of the equipment and test the data acquisition function. Provide control mode instruction documents, support users to develop software to control equipment parameters, and provide a full set of control instruction manuals.
