USR-G806-G

USR-G806-G

M2M Routers with Global Bands

M2M Routers with Global Bands


USR IOT's global version 4G M2M routers USR-G806-G, with full frequency bands, and can cover the global regions.

● M2M Routers/4G Cellular Routers, secure wireless routing for industrial remote access
● Worldwide LTE, UMTS/HSPA(+) and GSM/GPRS/EDGE coverage
● Providing reliable, seamless connectivity for M2M & IoT applications
● Support PPTP L2TP IPSEC OPENVPN GRE
● Support 2 10/100Base-T(X) self-adaptive Ethernet interface
● Hardware watchdog, rugged metal casing and Din-Rail mounting
● Support 802.11 b/g/n WLAN

4G LTE Industrial

cellular VPN router

High Reliability and Stability

High Speed Smart LTE Router

Remote Management, Remote Access
Efficient Batch configuration without on-site

Remote access: open the built-in web page of the router anywhere
without private network.
Remote maintenance: cloud based configuration, batch parameter
settings and firmware upgrading.
Online supervision: Real-time monitoring of traffic consumption,
network type and signal strength,understand the on-site network
status anytime and anywhere.
Exception push: the maintenance personnel receive the alarm
information in time when the network is abnormal.
Base station positioning: Precise positioning of the router on the
cloud.

Failover and network backup

Failover delivers redundant connectivity to ensure uptime,
whether your primary connection is wired or cellular.
If the primary connection fails, the backup kicks in.

Data Security, Multiple VPN

G806 supports mainstream VPN protocols, including
PPTP, L2TP, IPSec, OpenVPN, and GRE.
Multiple safe encryption methods make data safe
transmission up to financial grade.

Supports email alarm,SMS alarm,
abnormal alarm push in time

Support 2.4GHz WiFi , cover up to 100m.

Multi-layer link detection mechanism, automatic
redial and recovery.

Failover between 4G and WAN, ensures
automatic switch to alternative
backup connection

Integrating embedded cellular modem, Cellular routers G806 provides 3G/4G cellular network, Cellular routers also equipped with 2 fast Ethernet ports and supports Wi-Fi access.
Features with compact and rugged design it can be used as a reliable
failover connection or wireless communication in harsh environment.
It is suitable for large-scale distributed M2M/IoT applications,
such as smart express cabinets, charging piles, CCTV, bank ATM machines,
ticketing machines, traffic management,vending machines, medical device
networking, tower monitoring,construction sites,digital signage, electricity,
water conservancy, environmental protection, etc.

Cellular routers G806 supports VPN encryption which ensures data security, is applicable to various
self-service terminal scenarios such as ticket machines, community express cabinets,
vending machines, etc., users are able to remotely manage equipment and
reduce maintenance costs.

When the vehicle leaves, the terminal sensing device
will transmit the collected license plate number information
to the control center through industrial 4G router G806, the server will calculate
the parking time and payment amount, and transmit it to
the site,the driver can pay by scanning the code.
Wireless networking is optional for barriers, and WAN+4G
networking is optional for indoors. The whole process
network is fast, the remote management is convenient,
optimizes the operation cost, makes the parking
management more intelligent,creates a comfortable parking
experience

Nowadays, solar has been widely utilized as a renewable clean energy and a large
number of distributed solar power plants has been built and gone into operation.
It’s critical for monitoring and management such as real-time monitoring, fault
diagnosis, power prediction, active/reactive power control system and daily
maintenance such as part replacement or solar panel cleaning
in the distribution system.

4G LTE Industrial

cellular VPN router

High Reliability and Stability

High Speed Smart LTE Router

Remote Management, Remote Access
Efficient Batch configuration without on-site

Remote access: open the built-in web page of the router anywhere
without private network.
Remote maintenance: cloud based configuration, batch parameter
settings and firmware upgrading.
Online supervision: Real-time monitoring of traffic consumption,
network type and signal strength,understand the on-site network
status anytime and anywhere.
Exception push: the maintenance personnel receive the alarm
information in time when the network is abnormal.
Base station positioning: Precise positioning of the router on the
cloud.

Failover and network backup

Failover delivers redundant connectivity to ensure uptime,
whether your primary connection is wired or cellular.
If the primary connection fails, the backup kicks in.

Data Security, Multiple VPN

G806 supports mainstream VPN protocols, including
PPTP, L2TP, IPSec, OpenVPN, and GRE.
Multiple safe encryption methods make data safe
transmission up to financial grade.

Supports email alarm,SMS alarm,
abnormal alarm push in time

Support 2.4GHz WiFi , cover up to 100m.

Multi-layer link detection mechanism,
automatic redial and recovery.

Failover between 4G and WAN, ensures
automatic switch to alternative
backup connection

Integrating embedded cellular modem, Cellular routers G806 provides 3G/4G cellular network, Cellular routers also equipped with 2 fast Ethernet ports and supports Wi-Fi access.
Features with compact and rugged design it can be used as a reliable failover connection or wireless communication in harsh environment.
It is suitable for large-scale distributed M2M/IoT applications,such as smart express cabinets, charging piles, CCTV, bank ATM machines,ticketing machines, traffic management,vending machines, medical device networking, tower monitoring,construction sites,digital signage, electricity,water conservancy, environmental protection, etc.

Cellular routers G806 supports VPN encryption which ensures data security, is applicable to various
self-service terminal scenarios such as ticket machines, community express cabinets,
vending machines, etc., users are able to remotely manage equipment and reduce maintenance costs.

When the vehicle leaves, the terminal sensing device
will transmit the collected license plate number information
to the control center through industrial 4G router G806, the server will calculate the parking time and payment amount, and transmit it to the site,the driver can pay by scanning the code.
Wireless networking is optional for barriers, and WAN+4G
networking is optional for indoors. The whole process
network is fast, the remote management is convenient,
optimizes the operation cost, makes the parking
management more intelligent,creates a comfortable parking
experience

Nowadays, solar has been widely utilized as a renewable clean energy and a large number of distributed solar power plants has been built and gone into operation.
It’s critical for monitoring and management such as real-time monitoring, fault diagnosis, power prediction, active/reactive power control system and daily maintenance such as part replacement or solar panel cleaning in the distribution system.

Hardware Specifications
Cellular
Interface
Antenna 1 x SMA-K
Note: North America models: 2 x SMA 4G antenna connectors.
SIM card 1 x (3 V & 1.8 V) Standard 2FF SIM, drawer-type sim card slots
Ethernet 1 x WAN port (can be configured to LAN) 10/100 Mbps, compliance with IEEE 802.3, supports auto MDI/MDIX,1.5KV network isolation transformer protection
1 x LAN port, 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u standards, supports auto
MDI/MDIX,1.5KV network isolation transformer protection
Indicators LED PWR: always on after powered on
WLAN: always solid on when WiFi is enabled and working properly
WAN: solid when cable is connected, blinking when data is transmitting and
receiving
LAN : solid when cable is connected, blinking when data is transmitting and
receiving
2/3/4G mode indicator:2G led is on after connected to 2G network
                                        3G led is on after connected to 3G network
                                        Both leds is on after connected to 4G network
Signal strength:4 solid bars,strongest signal
WiFi Interface Standards & Frequency IEEE 802.11b/g/n,2.4GHz, AP mode
Data speed IEEE 802.11b/g,maximum 54Mbps.IEEE 802.11n,maximum 150Mbps
Antenna 1 x SMA-K
Transmission distance 80 meters by line of sight.Actual transmission distance depends on environment of the site.
Power Supply Adaptor DC 12V/1A
Connector DC Power Jack Barrel Type Female 5.5*2.1mm Round socket or 2 PIN industrial terminal block,reverse polarity protection
Input voltage DC 9~36V
Working power Average 175mA/12V
Physical
Characteristics
Housing Metal shell,IP30
Dimensions 110.0*94.0*29.0 mm(L*W*H)
Installation method Panel mounting, DIN-Rail mounting
EMC Static IEC61000-4-2, level 2
Pulsed Electric Field IEC61000-4-4, level 2
Surge IEC61000-4-5, level 2
Operating temperature -20℃~+70℃
Storage temperature -40℃~+125℃
Operating humidity 5%~95%RH(non-condensing)
Others Reload Pinhole reset button
TBD Debug interface (TTL Level)
Embedded Watchdog Device runs self-detection, auto recovers from malfunctions
Certificate CE,CCC,FCC,ANATEL,PTCRB,AT&T
Software Specifications
Network
Connection
WAN protocol  PPP, PPPoE, DHCP client
LAN protocol  ARP, DHCP server, NAT
4G network access Auto APN/VPDN, private network
Access authentication: CHAP/PAP
WLAN security Open system,WPA/WPA2 PSK
TKIP/AES encryption
IP routing Static routing
Network diagnosis Ping,route trace,DNS
Device
management
Configuration Web
Remote management Telnet, SSH, AT command,SNMP
PUSR platform Remote monitoring,remote upgrade,alarming,base station location,remote
access to web pages of the router
Security Failover backup Failover between 4G and WAN, ensures automatic switch to alternative
backup connection
Firewall DMZ, anti-DoS, Filtering (IP/Domain name/MAC address), Port Mapping, Access Control
VPN Supports PPTP, L2TP, GRE, IPSEC VPN (IKEv1), OPENVPN protocols
Service DDNS Remote access the device through domain name
Alarm  Email,SMS
Others NTP client
Timing task
Model USR-G806-G
Region Global
Frequency TDD-LTE B38/B39/B40/B41
FDD-LTE B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/B28
WCDMA B1/B2/B4/B5/B6/B8/B19
GSM B2/B3/B5/B8



Intelligent Parking loT Transmission

Intelligent Parking loT TransmissionMay 18,2020

The industrial router is used to optimize the network of the gate management system, so as to realize the fast transmission of operation management data, improve work efficiency and traffic jam.

Smart Photovoltaic System - USR IOT Photovoltaic System Data Transmission

Smart Photovoltaic System - USR IOT Photovoltaic System Data TransmissionMay 18,2020

In recent years, solar energy is used widely because many countries have put up the advocates of energy conservation and emission reduction and exploitation of renewable energies.

Smart Logistics Sorting System

Smart Logistics Sorting SystemJul 03,2020

Sorting is a logistics and distribution process that classifies goods quickly and accurately according to the type of goods, storage location and transportation destination, etc. How to use cellular routers to reduce the sorting error rate and manual intervention while improving the effective data transmission has become an urgent problem.

Solutions to Online Monitoring and Remote Control of the Rural Sewage

Solutions to Online Monitoring and Remote Control of the Rural SewageJul 03,2020

Sewage device monitoring platform: the monitoring center generally lies in control and dispatch department, which can establish a server with a fixed public network.

Case of Intelligent Nursing Home

Case of Intelligent Nursing HomeJul 15,2020

The solutions are around professional intelligent cellular router-USR-G806-G. Data of the blood pressure of the elderly can be sent to the monitoring platform in time and the nursing staff can get the info of the health conditions of the elderly for the first time.

Case of Intelligent Hotels

Case of Intelligent HotelsJul 15,2020

Industrial 4G routers are connected to the the cameras with internet access, which can monitor the flow of people in the hotels at any time to provide safety. Meanwhile, 4G transmission also eliminates the trouble of wiring.

Management Case of Intelligent Charging Piles

Management Case of Intelligent Charging Piles Jul 15,2020

It is expected that the global electric vehicle sales will climb to 2 million units in 2019. As a result, the electric vehicle charging facility will become increasingly significant in the future global transition to environmentally sustainable development.

  • Intelligent Parking loT Transmission
    The industrial router is used to optimize the network of the gate management system, so as to realize the fast transmission of operation management data, improve work efficiency and traffic jam.
  • Smart Photovoltaic System - USR IOT Photovoltaic System Data Transmission
    In recent years, solar energy is used widely because many countries have put up the advocates of energy conservation and emission reduction and exploitation of renewable energies.
  • Smart Logistics Sorting System
    Sorting is a logistics and distribution process that classifies goods quickly and accurately according to the type of goods, storage location and transportation destination, etc. How to use cellular routers to reduce the sorting error rate and manual intervention while improving the effective data transmission has become an urgent problem.
  • Solutions to Online Monitoring and Remote Control of the Rural Sewage
    Sewage device monitoring platform: the monitoring center generally lies in control and dispatch department, which can establish a server with a fixed public network.
  • Case of Intelligent Nursing Home
    The solutions are around professional intelligent cellular router-USR-G806-G. Data of the blood pressure of the elderly can be sent to the monitoring platform in time and the nursing staff can get the info of the health conditions of the elderly for the first time.
  • Case of Intelligent Hotels
    Industrial 4G routers are connected to the the cameras with internet access, which can monitor the flow of people in the hotels at any time to provide safety. Meanwhile, 4G transmission also eliminates the trouble of wiring.
  • Management Case of Intelligent Charging Piles
    It is expected that the global electric vehicle sales will climb to 2 million units in 2019. As a result, the electric vehicle charging facility will become increasingly significant in the future global transition to environmentally sustainable development.

Related Products

Request a Quote

Request a quote get more products/services/promotions.We will reply to you in a business day.
(Your email address will not be shared with a third party.)
